1.1/16 " JIC M X 1.1/16 " JIC M 90 DEG SWVL 3000 PSI STL
Code:
9SS12J12-J12
Sales Unit:
EA
Description
Reduce hose twisting and simplify hydraulic hose routing with the Hydraulics Inc 9SS dual-plane hydraulic swivel with 1 1/16" JIC Male and 1 1/16" JIC Male connections. Its dual-plane movement helps hose assemblies follow changes in equipment position. Maximum working pressure: 3,000 psi.
Product Summary
| Part Number | 9SS12J12-J12 |
|---|---|
| Product Type | Hydraulic Swivel |
| Series | 9SS Dual Plane |
| Configuration | Dual Plane |
| End A | 1 1/16" JIC Male |
| End B | 1 1/16" JIC Male |
| Material | Steel |
| Maximum Working Pressure | 3,000 psi |
Product Details
The 9SS series combines angular and inline swivel movement to accommodate hose routing in two planes. Low rotational resistance and low pressure drop support smooth articulation and efficient fluid transfer.
- Movement in two planes helps accommodate changing hose alignment.
- Replaceable seals support servicing of compatible assemblies.
Note: Confirm dimensions, connections, sealing method and fluid compatibility before ordering. Use within the rating of the lowest-rated system component. Rotation speed and external loading must suit the application.
