1/4" BSPP F X 1/4" BSPP STR SWVL 5000 PSI STL
Description
Reduce hose twisting and simplify hydraulic hose routing with the Hydraulics Inc HS Heavy Duty inline hydraulic swivel with 1/4" BSPP Female and 1/4" BSPP Female connections. Its straight-through layout allows the hose to rotate along the line in demanding hydraulic applications. Maximum working pressure: 5,000 psi.
Product Summary
| Part Number | HS6BF4-BF4 |
|---|---|
| Product Type | Hydraulic Swivel |
| Series | HS Heavy Duty Inline |
| Configuration | Straight / Inline |
| End A | 1/4" BSPP Female |
| End B | 1/4" BSPP Female |
| Material | Steel |
| Maximum Working Pressure | 5,000 psi |
Product Details
Built for demanding inline swivel applications, the HS series combines hardened alloy-steel components with an improved bearing arrangement. Dual bearing races improve resistance to side loading, while low rotational resistance helps the hose follow equipment movement.
- Two bearing races improve resistance to side loading.
- A permanently lubricated bearing supports smooth movement with low rotational resistance.
- The finished internal bore helps prolong seal life, and replaceable seals support maintenance.
- A low-restriction flow path helps limit pressure loss.
Note: Confirm dimensions, connections, sealing method and fluid compatibility before ordering. Use within the rating of the lowest-rated system component. Rotation speed and external loading must suit the application.
