1" BSPP F X 1" BSPP F BITUMEN STR SWVL
Description
Reduce hose twisting and simplify hydraulic hose routing with the Hydraulics Inc HS Heavy Duty inline hydraulic swivel with 1" BSPP Female and 1" BSPP Female connections. Its straight-through layout allows the hose to rotate along the line in demanding hydraulic applications.
Product Summary
| Part Number | HS16BF16-BF16-V |
|---|---|
| Product Type | Hydraulic Swivel |
| Series | HS Heavy Duty Inline |
| Configuration | Straight / Inline |
| End A | 1" BSPP Female |
| End B | 1" BSPP Female |
| Material | Steel |
Product Details
Built for demanding inline swivel applications, the HS series combines hardened alloy-steel components with an improved bearing arrangement. Dual bearing races improve resistance to side loading, while low rotational resistance helps the hose follow equipment movement. This Viton / bitumen version provides an option for applications requiring compatible fluorocarbon seals. Match the seal compound to the fluid and operating temperature.
- Two bearing races improve resistance to side loading.
- A permanently lubricated bearing supports smooth movement with low rotational resistance.
- The finished internal bore helps prolong seal life, and replaceable seals support maintenance.
- A low-restriction flow path helps limit pressure loss.
Note: Confirm dimensions, connections, sealing method and fluid compatibility before ordering. Use within the rating of the lowest-rated system component. Rotation speed and external loading must suit the application. Contact Fluid Fittings to confirm the working pressure for this exact configuration.
